Industrial Sawdust Sand Sludg Sea Salt Single Cylinder Rotary Dryer
Description
Single cylinder Rotary dryer is widely used for drying slag
limestone,coal powder,slag,clay,etc.The dryer can also be used in
building materials,metallurgy,chemical, and cement industry.Rotary
Dryer mainly consists of dryer body,raw material feeding
plate,driving and supporting device,seal ring,etc.Dryer can be
generally divided into four types,they are rotary dryer,triple-drum
dryer,indirect heat transfer dryer,vertical dryer.Different kind of
dryer has its own characters and advantages,the specific choice of
a special dryer depends on different elements.
Main Features
- 1.Our dryer adopts new Spreading plate device,which has
guidance,flow,material functions;
- 2.It can make the material contained in the dryer radial
cross-section to full uniform,the material will become thin and
all;
- 3.The state of the heat flow entirely,to achieve the purpose of
making full use of the heat;
- 4.Our dryer chooses reasonable operating parameters,coal
consumption and power consumption of general baked dry machine more
than 10-15%,one machine yields above 10-15%;
- 5.It has been widely used in the cement and mineral processing
enterprise.
1. Yuhong coal dryer, with strong overload capacity, large
quantity, less fuel consumption, low dry cost; Applies the
downstream drying method, flue gas and wet material in the dryer on
one side of the dryer, can take advantage of the high temperature
gas to achieve high evaporative force, low temperature dryer
output, with high efficiency thermal;
2. Can change the working parameters according to different
material properties, the material in the drying cylinder body can
form a durable curtain fabric and more convenient heat exchange;
3. New type of feeding and unloading device, preventing food blockage
of drum dryers, uninterrupted and uneven return phenomenon, reduce
the load of dust collection system;
4. A type of internal structure, to enhance the cleaning effect of
dispersed material and thermal conductivity, remove the cylinder in
moisture, has more flexible adaptation of adhesion and moisture of
materials;
5. In the new type of coal slurry drying device to achieve "zero
thrust", greatly reducing the wear of the wheels, the cylinder has
smooth and reliable operation;
6. The dryer acquires a "wheel self-adjusting device", makes the
wheel and roller ring with linear contact, thereby greatly reducing
wear and energy loss; Adopt the unique technology of large carbon
retardation absorption, ensure the uniformity of coal drying.
| Spec | Inner diameter of cylinder(mm) | Tube length (mm) | Sloup (°) | Speed (r/min) | Motor Power (Kw) | Output (t/h) | Inlet temperature (℃) | G.W. (t) |
| Φ1.0×10m | 1000 | 10000 | 2.5 | 3.4 | 4 | 0.6-1.8 | ≤700℃ | 5.6 |
| Φ1.2×12m | 1200 | 12000 | 2.5 | 3.4 | 11 | 0.8-2.5 | 15 |
| Φ1.5×14m | 1500 | 14000 | 2.5 | 3.4 | 15 | 1.8-4 | 19.6 |
| Φ1.8×15m | 1800 | 15000 | 2.5 | 4.04 | 18.5 | 2.8-6.5 | 25 |
| Φ1.8×20m | 1800 | 20000 | 2.5 | 3.1 | 22 | 5-8 | 32.2 |
| Φ2.0×18m | 2000 | 18000 | 2.5 | 3.16 | 30 | 6-10 | 38.8 |
| Φ2.2×20m | 2200 | 20000 | 2.5 | 3.68 | 37 | 6.5-11 | 47 |
| Φ2.2×22m | 2200 | 22000 | 2.2 | 2.9 | 37 | 7-12 | 50 |
| Φ2.4×22m | 2400 | 22000 | 2.5 | 3.27 | 45 | 7.5-14 | 62 |
| Φ2.6×24m | 2600 | 24000 | 2.5 | 3.2 | 55 | 8-17 | 72.5 |
| Φ2.8×22m | 2800 | 22000 | 2.5 | 3.4 | 132 | 28-32 | 94 |
| Φ3.0×28m | 3000 | 28000 | 2.5 | 3.2 | 75 | 32-36 | 105 |
| Φ3.2×30m | 3200 | 30000 | 3-5 | 3.2 | 90 | 43-50 | 700-800℃ | 118 |
| Φ3.6×32m | 3600 | 32000 | 3-5 | 3.0 | 160 | 60-76 | 143 |
| Φ4.0×36m | 4000 | 36000 | 3-5 | 3.0 | 200 | 82-90 | 189 |
| Φ4.6×42m | 4600 | 42000 | 3-5 | 3.0 | 280 | 100-110 | 290 |
Application
The quality of building materials continues to increase, energy and
raw material consumption are declining year by year, new types of
new building materials continue to emerge, and building materials
are constantly upgraded. As a result, the requirements for the
processing technology of building materials have been continuously
improved. For example, the control requirements for impurities and
moisture content of raw materials have been continuously improved.
Only in this way can products with guaranteed quality be produced.
Customer case
Working principle
1.Materials are sent to the hopper of rotary dryer by belt conveyor
or bucket elevator;
2.Materials enter the barrel installed with slope to horizontal
line from the higher side,and hot air enters the barrel from the
lower side,and the materials and hot air mix together;
3.Materials go to the lower side by gravity when the barrel is
rotating;
4.Lifters on the inner side of barrel lift materials up and down in
order to make materials and hot air mix completely,which is
designed to improve the producing efficiency of rotary dryer.
FAQ
Q1: Why choose YuHong machinery?
A1: 1. Up-to-date design, CAD calculation and simulation;
2. ISO,BV,SGS,CE quapty control manufacturing;
3. Over 30 years experience, export to over 50 countries;
4. Highest standard to suit operators' use;
5. World class quality at affordable price.
Remarks: The price will depend on different models. Reply message
,you will get 5% discount price.
Q2: What are the requirements for rotary dryer material?
A2: Our Yuhong has a high standard on choosing material of rotary
dryer.
1.Using very high grade steel plate (i.e. Q235, Q345) on
structuring part;
2. Using wear-resistant steel (i.e. ZG35, ZGMn13, 65Mn, 35CrMo,
ZG60Si2CrA) on quick-wear parts;
3. The motor, reducer, bearing, belt, bolts are Chinese top 5
brands;
4. Metallurgy performance must be considered during designing,
cutting, bending, fitting&welding.
Q3: What information do we need to provide you the reasonable model
and best quotation?
A3: 1. What is the raw material?
2.Raw material maximum feeding size (mm or mesh)?
3. Final products size (mm or mesh) and usage?
4. What is the capacity per hour?
